Mean Well ELG-240-C1400B-3Y LED driver 239.4W 1400mA dimmable outdoor

Mean Well
Order Code:

05-0497

Brand: Mean Well MPN: ELG-240-C1400B-3Y EAN-13: 4021087037785
Qty Was Unit Price (Ex VAT)
1+ £55.03 £49.08
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 13/12/2025

The Mean Well ELG-240-C1400B-3Y LED driver delivers constant current power of 239.4 W with a current rating of 1400 mA and a voltage range of 86 - 171 V DC, featuring a 3-in-1 dimmer for versatile lighting control. This dimmable driver is suitable for outdoor use, is approved for use on furniture, and includes built-in surge protection and a PFC circuit, making it ideal for powering LED strips
Type LED driver
Connection Open end cable
Dim (L x W x H) 244 x 71 x 37.5 mm
Factory colour Metal
Height 37.5mm
IP Rating IP67
Length 244mm
Max. output current 1400mA
Max. power 239.4W
Max. temperature +85°C
Min. temperature -40°C
Misc Attribute 1 Constant current
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 1.4A
Output voltage (max.) 171V DC
Output voltage (min.) 86V DC
Power range 239.4 W (max)
Protection Class I
Test mark CE, CB, MM, UL, ENEC
Width 71mm
