Mean Well ELG-200-C2100B-3Y ELG LED driver 2100mA 48-96V dimmable outdoor

The Mean Well ELG-200-C2100B-3Y is a constant current LED driver delivering 2100 mA with voltage capability between 48 and 96 V DC, designed for outdoor use with built-in surge protection and a PFC circuit. Suitable for installation on flammable surfaces and approved for use on furniture, this dimmable unit offers a 3-in-1 dimmer control option. Typical applications include powering LED strips and other LED lighting systems while ensuring safe and reliable

Type	LED driver
Connection	Open end cable
Dim	(L x W x H) 244 x 71 x 37.5 mm
Factory colour	Metal
Height	37.5mm
IP Rating	IP67
Length	244mm
Max. output current	2100mA
Max. power	2100W
Max. temperature	+85°C
Min. temperature	-40°C
Misc Attribute 1	Constant current
Misc Attribute 2	Pulsed
Number of Inputs	1
Number of Outputs	1
Output current (max.) - rounded	2.1A
Output voltage (max.)	96V DC
Output voltage (min.)	48V DC
Power range	2100 W (max)
Test mark	CE, CB, MM, UL, ENEC
Width	71mm
