Mean Well ELG-150-C1050DA-3Y ELG series LED driver 105W 1400mA DALI dimmable

Mean Well
Order Code:

05-0466

Brand: Mean Well MPN: ELG-150-C1050DA-3Y EAN-13: 4021087038287
Qty Unit Price (Ex VAT)
1+ £37.52
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 27/12/2025

The Mean Well ELG-150-C1050DA-3Y LED driver is a constant current power supply rated at 105 W, delivering 1400 mA with a voltage range of 72 to 143 V DC and DALI dimmable functionality. It includes features like a PFC circuit, surge protection, and is suitable for use on flammable surfaces and furniture, making it ideal for outdoor lighting applications. This driver is particularly well-suited for LED strips and provides reliable performance
Type LED driver
Output Voltage 72V DC
Max Output Power 105W
Output Current 1.4A
Colour Metal
Connection Open end cable
Dimensions (L x W x H) 219 x 63 x 35.5 mm
Height 35.5mm
IP Rating IP67
Length 219mm
Max. output current 1400mA
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant current
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Test mark CE, CB, MM, UL, ENEC
Width 63mm
