Mean Well ELG-150-42AB-3Y LED driver 150W dimmable outdoor surge protection

Mean Well
Standard range
Order Code:

05-0461

Brand: Mean Well MPN: ELG-150-42AB-3Y
Qty Unit Price (Ex VAT)
1+ £42.79
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
3 in stock, despatched in 4 working days

The Mean Well ELG-150-42AB-3Y is a LED driver with constant voltage, providing 150 W power output, and operates within a current range of 1.8 to 3.57 A at 37.8 to 46.2 V DC. This driver is dimmable, adjustable, and includes features like surge protection and a PFC circuit, making it suitable for both indoor furniture use and outdoor environments. Common applications include powering LED strips and other low
Type LED driver
Connection Open end cable
Dim (L x W x H) 219 x 63 x 35.5 mm
Factory colour Metal
Height 35.5mm
IP rating IP65
Length 219mm
Max. output current 3.57A
Max. power 150W
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant voltage
Misc Attribute 2 Pulsed
No. of inputs 1
No. of outputs 1
Output current (max.) - rounded 3.57A
Output current (min.) 1.8A
Output voltage (max.) 46.2V DC
Output voltage (min.) 37.8V DC
Power range 150 W (max)
Protection class I
Test mark SELV, UL, MM, ENEC, CB, CE
Weight 950g
Width 63mm
