Mean Well ELG-100-C1050B-3Y ELG series LED driver 99.75W 1050mA dimmable

Mean Well
Order Code:

05-0448

Brand: Mean Well MPN: ELG-100-C1050B-3Y EAN-13: 4021087038539
Qty Was Unit Price (Ex VAT)
1+ £40.86 £35.22
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well ELG-100-C1050B-3Y is a constant current LED driver designed for outdoor use with a power output of 99.75 W and a current rating of 1050 mA. Equipped with a 3-in-1 dimmer, PFC circuit, and surge protection, it is suitable for flammable surfaces and approved for use on furniture. This LED driver is ideal for powering LED strips and other LED lighting applications requiring reliable performance and dimmability within
Type LED driver
Connection Open end cable
Dim (L x W x H) 199 x 63 x 35.5 mm
Factory colour Metal
Height 35.5mm
IP Rating IP67
Length 199mm
Max. output current 1050mA
Max. power 99.75W
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant current
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 1.05A
Output voltage (max.) 95V DC
Output voltage (min.) 48V DC
Power range 99.75 W (max)
Protection Class I
Test mark CE, CB, MM, SELV, UL, ENEC
Width 63mm
