Mean Well ELG-100-48AB-3Y elg series LED driver 96W 3-in-1 dimmable

Mean Well
Order Code:

05-0447

Brand: Mean Well MPN: ELG-100-48AB-3Y EAN-13: 4021087050548
Qty Unit Price (Ex VAT)
1+ £33.94
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

Mean Well's ELG-100-48AB-3Y is a dimmable LED driver with a constant voltage of 96 W, operating at 43.2 - 52.8 V DC and 1 - 2 A. Its features include surge protection, adjustable current, a PFC circuit, and suitability for outdoor use and flammable surfaces, making it ideal for lighting applications on furniture and outdoor environments. It is engineered for reliability with overvoltage protection and 3-in
Type LED driver
Connection Open end cable
Dim (L x W x H) 199 x 63 x 35.5 mm
Factory colour Metal
Height 35.5mm
IP Rating IP65
Length 199mm
Max. output current 2A
Max. power 96W
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant voltage
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 2A
Output current (min.) 1A
Output voltage (max.) 52.8V DC
Output voltage (min.) 43.2V DC
Power range 96 W (max)
Protection Class I
Test mark SELV, UL, MM, ENEC, CB, CE
Width 63mm
