Mean Well ELG-100-24AB-3Y ELG series LED driver 96W constant voltage

Mean Well
Order Code:

05-0443

Brand: Mean Well MPN: ELG-100-24AB-3Y EAN-13: 4021087050579
Qty Unit Price (Ex VAT)
1+ £33.94
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well ELG-100-24AB-3Y LED driver is a constant voltage power supply with a rating of 96 W and an output range of 21.6 - 26.4 V DC at 2 - 4 A. It features a 3-in-1 dimmer, surge protection, and is suitable for use on furniture and flammable surfaces. This dimmable, adjustable LED driver, with a PFC circuit, is designed for outdoor use, making
Type LED driver
Connection Open end cable
Dim (L x W x H) 199 x 63 x 35.5 mm
Factory colour Metal
Height 35.5mm
IP Rating IP65
Length 199mm
Max. output current 4A
Max. power 96W
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant voltage
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 4A
Output current (min.) 2A
Output voltage (max.) 26.4V DC
Output voltage (min.) 21.6V DC
Power range 96 W (max)
Protection Class I
Test mark SELV, UL, MM, ENEC, CB, CE
Width 63mm
