Mean Well DRC-100B PSU 27.6V DC 2.25A 96W DIN rail mount 2 outputs

The Mean Well DRC-100B is a rail-mounted PSU designed for DIN-rail applications. It delivers a 27.6 V DC output with a current rating of 2.25 A and a total power of 96 W. This power supply unit is ideal for industrial settings where stable and reliable power distribution is required.

Type	Rail mounted PSU (DIN)
Nominal value output current 1	2.25A
Number of Outputs	2
Power Rating	96W
Depth	55mm
Dimensions (L x W x H)	55 x 90 x 100mm
Height	100mm
Max. output current 1	2.25A
Maximum input voltage [AC]	264V
Minimum Input Voltage [AC]	90V
Misc Attribute 1	switched-mode
Misc Attribute 2	Synchronised
Nominal value output voltage 1 [DC]	27.6V
Number of Inputs	1
Type of electric connection	Screw terminal
Weight	370g
Width	90mm
