Mean Well DLC03C-05 DLC series DC/DC converter 3W dual output 300mA

Mean Well
Standard range
Order Code:

05-0366

Brand: Mean Well MPN: DLC03C-05
Qty Unit Price (Ex VAT)
1+ £9.72
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
1 in stock, despatched in 4 working days

The Mean Well DLC03C-05 is a direct current converter module capable of delivering 300 mA at 3 W, with two output channels. It is compact and suitable for applications that require reliable DC/DC conversion. This module is commonly used in electronic circuits and systems requiring stable voltage transformation from one DC level to another.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 22.1 x 13.8 x 8.55 mm
Efficiency (max.) 80%
Height 8.55mm
Input voltage (max.) 75V DC
Insulation voltage 1500V DC
Length 22.1mm
Max. output current 300mA
Min. input voltage 36V DC
Misc Attribute DLC03C-05
No. of outputs 2
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 300mA
Power 3W
PSU features DC-to-DC converter
Weight 4.5g
Width 13.8mm
