Mean Well DKM10B-12 DKM029 dc/dc converter 416mA 10W dual output

Mean Well
Standard range
Order Code:

05-0344

Brand: Mean Well MPN: DKM10B-12
Qty Unit Price (Ex VAT)
1+ £20.57
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well DKM10B-12 is a DC/DC converter module with a current rating of 416 mA and a power output of 10 W. It features dual outputs and is ideal for converting direct current in electronic designs where reliable voltage management is crucial. Typical applications include industrial control systems and telecommunications equipment.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 25.4 x 25.4 x 10.2 mm
Efficiency (max.) 88%
Height 10.2mm
Input voltage (max.) 32V DC
Insulation voltage 1500V DC
Length 25.4mm
Max. output current 416mA
Min. input voltage 4.75V DC
Misc Attribute DKM10B-12
No. of outputs 2
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 416mA
Power 10W
PSU features DC-to-DC converter
Weight 18g
Width 25.4mm
