Mean Well DDR-60L-5 DC/DC converter DIN rail 5V 12A 60W single output

Mean Well
Standard range
Order Code:

05-0316

Brand: Mean Well MPN: DDR-60L-5
Qty Unit Price (Ex VAT)
1+ £27.59
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
17 in stock, despatched in 4 working days

The Mean Well DDR-60L-5 is a rail-mounted DC/DC converter designed for industrial applications, providing a single output of 5 V DC at 12 A with a power capacity of 60 W. This compact and efficient power supply unit is ideal for use in automation systems and industrial equipment where a stable DC voltage is crucial. Its DIN rail mounting makes it easy to install and integrate into existing electrical panels.
Type Rail mounted DC/DC converter (DIN)
Connection Clamp
Dim (L x W x H) 52.5 x 54.5 x 90 mm
Efficiency 87.5%
Height 90mm
Input Voltage 18-75V DC
Input voltage (max.) 75V DC
Length 52.5mm
Manufacturer part # DDR-60L-5
Max. output current 12A
Min. input voltage 18V DC
Misc Attribute DDR-60L-5
MTBF 611000h
No. of outputs 1
Nominal input voltage 48 V/DC
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 12A
Output type (power supply units) Adjustable
Output voltage 5V DC
Output voltage (max.) 5.5V DC
Output voltage (min.) 4.5V DC
Output voltage (nominal) 5V DC
Power 60W
Weight 216g
Width 54.5mm
