Mean Well DDR-60L-12 Rail DC/DC converter 12V 5A 60W 1 output 1 pc

Mean Well
Standard range
Order Code:

05-0312

Brand: Mean Well MPN: DDR-60L-12
Qty Unit Price (Ex VAT)
1+ £35.58
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
70 in stock, despatched in 4 working days

The Mean Well DDR-60L-12 is a rail-mounted DC/DC converter that delivers 12 V DC at a current rating of 5 A, with a power capacity of 60 W and a single output. It is ideal for industrial applications where stable and efficient power conversion from one DC voltage level to another is required. Designed for DIN rail mounting, this unit provides reliable performance in various industrial power supply setups.
Type Rail mounted DC/DC converter (DIN)
Connection Clamp
Dim (L x W x H) 52.5 x 54.5 x 90 mm
Efficiency 91%
Height 90mm
Input Voltage 18-75V DC
Input voltage (max.) 75V DC
Length 52.5mm
Manufacturer part # DDR-60L-12
Max. output current 5A
Min. input voltage 18V DC
Misc Attribute DDR-60L-12
MTBF 611000h
No. of outputs 1
Nominal input voltage 48 V/DC
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 5A
Output type (power supply units) Adjustable
Output voltage 12V DC
Output voltage (max.) 13.2V DC
Output voltage (min.) 9V DC
Output voltage (nominal) 12V DC
Power 60W
Weight 216g
Width 54.5mm
