Mean Well DDR-60G-15 DC/DC converter 15V 4A 60W rail mounted DIN 1 output

Name: Mean Well DDR-60G-15 DC/DC converter 15V 4A 60W rail mounted DIN 1 output
Brand: Mean Well
Price: 28.29 GBP
Availability: InStock

Standard range

Order Code:

05-0308

Brand: Mean Well MPN: DDR-60G-15

RoHS Compliant
Country of Origin: China
Free UK shipping available
View Full Product Range (4)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£28.29

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

4 in stock, despatched in 4 working days

Product Details
Product Range
Data Sheets
Quick Quote

The Mean Well DDR-60G-15 is a rail-mounted DC/DC converter suitable for industrial applications. It delivers a 15 V DC output at 4 A and has a total power capacity of 60 W. This unit is commonly used in industrial power supply systems due to its robust design and reliable performance.

Type	Rail mounted DC/DC converter (DIN)
Connection	Clamp
Dim	(L x W x H) 52.5 x 54.5 x 90 mm
Efficiency	91%
Height	90mm
Input Voltage	9-36V DC
Input voltage (max.)	36V DC
Length	52.5mm
Manufacturer part #	DDR-60G-15
Max. output current	4A
Min. input voltage	9V DC
Misc Attribute	DDR-60G-15
MTBF	611000h
No. of outputs	1
Nominal input voltage	24 V/DC
Operating temperature (max.)	+85°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	4A
Output type (power supply units)	Adjustable
Output voltage	15V DC
Output voltage (max.)	16.5V DC
Output voltage (min.)	13.5V DC
Output voltage (nominal)	15V DC
Power	60W
Weight	216g
Width	54.5mm
