Mean Well DDR-60G-12 DC/DC converter 12V 5A 60W DIN rail mounted

Mean Well
Standard range
Order Code:

05-0307

Brand: Mean Well MPN: DDR-60G-12
Qty Unit Price (Ex VAT)
1+ £35.58
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
71 in stock, despatched in 4 working days

The Mean Well DDR-60G-12 is a rail-mounted DC/DC converter, providing a 12 V DC output at 5 A with a power rating of 60 W. It features a single output and is ideal for industrial applications where reliable power supply is needed. The unit is designed for easy installation on DIN rails and is a solid choice for powering electronics in industrial environments.
Type Rail mounted DC/DC converter (DIN)
Connection Clamp
Dim (L x W x H) 52.5 x 54.5 x 90 mm
Efficiency 91%
Height 90mm
Input Voltage 9-36V DC
Input voltage (max.) 36V DC
Length 52.5mm
Manufacturer part # DDR-60G-12
Max. output current 5A
Min. input voltage 9V DC
Misc Attribute DDR-60G-12
MTBF 611000h
No. of outputs 1
Nominal input voltage 24 V/DC
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 5A
Output type (power supply units) Adjustable
Output voltage 12V DC
Output voltage (max.) 13.2V DC
Output voltage (min.) 9V DC
Output voltage (nominal) 12V DC
Power 60W
Weight 216g
Width 54.5mm
