Mean Well DDR-30G-24 Rail DC/DC converter 24V 1.25A 30W Single Output

The Mean Well DDR-30G-24 is a rail-mounted DC/DC converter specifically designed for DIN rail installation. It provides a 24 V DC output at 1.25 A, delivering a power output of 30 W with a single output. This industrial power supply unit is ideal for applications requiring stable DC power in environments where efficient rail mounting is essential.

Nominal value output current 1	1.25A
Number of Outputs	1
Power Rating	30W
Depth	35mm
Dimensions (L x W x H)	35 x 54.5 x 90mm
Efficiency	89%
Height	90mm
Input voltage DC	9-36V
Max. output current 1	1.25A
Maximum input voltage [DC]	36V
Maximum Operating Temperature	+85°C
Minimum Input Voltage [DC]	9V
MTBF	483300h
Nominal Input Voltage	24 /DCV
Nominal value output voltage 1 [DC]	24V
Operating temperature (min.)	-40°C
Output type (power supply units)	Adjustable
Type of electric connection	Clamp
Voltage type (supply voltage)	Rail mounted DC/DC converter (DIN)
Weight	120g
Width	54.5mm
