Mean Well DDR-30G-12 rail DC/DC converter 12V 2.5A 30W 1 output DIN rail

Mean Well
Order Code:

05-0294

Brand: Mean Well MPN: DDR-30G-12 EAN-13: 4021087050784
Qty Was Unit Price (Ex VAT)
1+ £23.28 £19.66
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
144 in stock, despatched in 4 working days

The Mean Well DDR-30G-12 is a rail-mounted DC/DC converter designed for industrial power applications. It delivers 12 V DC at 2.5 A, providing a power output of 30 W with a single output channel. This module is ideal for DIN rail installations requiring stable and efficient power conversion.
Type Rail mounted DC/DC converter (DIN)
Output Voltage 12V DC
Output Current 2.5A
Number of Outputs 1
Power Rating 30W
Connection Clamp
Dim (L x W x H) 35 x 54.5 x 90 mm
Efficiency 86%
Height 90mm
Input Voltage 9-36V DC
Input voltage (max.) 36V DC
Length 35mm
Max. output current 2.5A
Min. input voltage 9V DC
MTBF 483300h
Nominal Input Voltage 24 V/DC
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output type (power supply units) Adjustable
Width 54.5mm
