Mean Well DDR-240B-48 rail DC/DC converter 48V 5A 240W 1 output DIN rail

Mean Well
Order Code:

05-0289

Brand: Mean Well MPN: DDR-240B-48 EAN-13: 4021087050838
Qty Unit Price (Ex VAT)
1+ £83.66
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well DDR-240B-48 is a rail mounted DC/DC converter suitable for industrial applications. It provides a 48 V DC output with a current rating of 5 A and a power capacity of 240 W. Ideal for use in industrial power supply systems, this single-output unit ensures reliable and efficient power conversion.
Type Rail mounted DC/DC converter (DIN)
Output Voltage 48V DC
Connection Clamp
Dim (L x W x H) 40 x 113.5 x 125.2 mm
Efficiency 90%
Height 125.2mm
Input Voltage 16,8-33,6V DC
Input voltage (max.) 33.6V DC
Length 40mm
Max. output current 5A
Min. input voltage 16.8V DC
MTBF 484900h
Nominal Input Voltage 24 V/DC
Number of Outputs 1
Operating temperature (max.) +70°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 5A
Output type (power supply units) Adjustable
Output voltage (max.) 54V DC
Output voltage (min.) 48V DC
Output voltage (nominal) 48V DC
Power 240W
Width 113.5mm
