Mean Well DDR-15G-15 DIN rail DC/DC converter 15V 1A 15W 1 output

The Mean Well DDR-15G-15 is a rail mounted DC/DC converter with a single output providing 15 V DC at 1 A, offering a power capacity of 15 W. This industrial power supply unit is ideal for DIN rail installations where efficient voltage conversion is needed. Typical applications include automation systems, industrial control panels, and telecommunications equipment.

Number of Outputs	1
Power Rating	15W
1st secondary output voltage	15V
2nd secondary output voltage	15V
3rd secondary output voltage	15V
Depth	17.5mm
Dimensions (L x W x H)	17.5 x 54.5 x 90mm
Efficiency	85%
Height	90mm
Input voltage DC	9-36V
Maximum input voltage [DC]	36V
Maximum Operating Temperature	+85°C
Minimum Input Voltage [DC]	9V
MTBF	907000h
Nominal Input Voltage	24 /DCV
Nominal value output voltage 1 [DC]	15V
Nominal value output voltage 2	15V
Nominal value output voltage 3	15V
Operating temperature (min.)	-40°C
Output type (power supply units)	Adjustable
Output voltage stabilized	15V
Type of electric connection	Clamp
Voltage type (supply voltage)	Rail mounted DC/DC converter (DIN)
Weight	68g
Width	54.5mm
