Mean Well DDR-120B-12 DC/DC rail converter 12V 10A 120W single output

Mean Well
Standard range
Order Code:

05-0269

Brand: Mean Well MPN: DDR-120B-12
Qty Unit Price (Ex VAT)
1+ £53.12
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
8 in stock, despatched in 4 working days

The Mean Well DDR-120B-12 is a rail mounted DC/DC converter with a single output of 12 V DC and a current rating of 10 A. It delivers a power output of 120 W and is designed for industrial applications. This unit is ideal for use in settings where reliable DC power is needed on a DIN rail configuration.
Type Rail mounted DC/DC converter (DIN)
Connection Clamp
Dim (L x W x H) 32 x 102 x 125.2 mm
Efficiency 89%
Height 125.2mm
Input Voltage 16,8-33.6V DC
Input voltage (max.) 33.6V DC
Length 32mm
Manufacturer part # DDR-120B-12
Max. output current 10A
Min. input voltage 16.8V DC
Misc Attribute DDR-120B-12
MTBF 214600h
No. of outputs 1
Nominal input voltage 24 V/DC
Operating temperature (max.) +70°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 10A
Output type (power supply units) Adjustable
Output voltage 12V DC
Output voltage (max.) 14V DC
Output voltage (min.) 9V DC
Output voltage (nominal) 12V DC
Power 120W
Weight 510g
Width 102mm
