Mean Well DDR-120A-48 Rail DC/DC converter 48V 2.1A 100.8W 1 output

The Mean Well DDR-120A-48 is a rail-mounted DC/DC converter with 48 V DC voltage output, supporting up to 2.1 A current and 100.8 W power. It features a single output, making it suitable for industrial applications requiring stable power conversion. This industrial power supply unit is typically used in environments requiring reliable power across various devices mounted on DIN rails.

Nominal value output current 1	2.1A
Number of Outputs	1
Power Rating	100.8W
1st secondary output voltage	48V
2nd secondary output voltage	48V
3rd secondary output voltage	48V
Depth	32mm
Dimensions (L x W x H)	32 x 102 x 125.2mm
Efficiency	88.5%
Height	125.2mm
Input voltage DC	18V
Max. output current 1	-120A
Max. output current 2	-120A
Max. output current 3	-120A
Maximum Operating Temperature	+70°C
Minimum Input Voltage [DC]	9V
MTBF	214600h
Nominal Input Voltage	12 /DCV
Nominal value output voltage 1 [DC]	48V
Nominal value output voltage 2	48V
Nominal value output voltage 3	48V
Operating temperature (min.)	-40°C
Output type (power supply units)	Adjustable
Output voltage stabilized	48V
Rated supply voltage AC 60 Hz	48V
Rated supply voltage DC	48V
Type of electric connection	Clamp
Voltage type (supply voltage)	Rail mounted DC/DC converter (DIN)
Weight	510g
Width	102mm
