Mean Well DCWN03E-05 DCWN03 series DC/DC converter 300 mA 3 W 2 outputs

Mean Well
Order Code:

05-0254

Brand: Mean Well MPN: DCWN03E-05 EAN-13: 4021087046879
Qty Unit Price (Ex VAT)
1+ £10.65
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well DCWN03E-05 is a DC/DC converter module providing dual outputs with a maximum output power of 3 watts and a current rating of 300 mA. This module is suitable for applications requiring stable voltage conversion, such as in industrial control systems and portable electronics. With efficient energy conversion, it ensures reliable performance in compact electronic circuit designs.
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 10.2 mm
Efficiency (max.) 77%
Height 10.2mm
Input voltage (max.) 9V DC
Insulation Voltage 3000V DC
Length 31.8mm
Max. output current 300mA
Min. input voltage 4.5V DC
Number of Outputs 2
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 300mA
Power 3W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 20.3mm
