Mean Well DCWN03C-12 DCWN03 DC/DC converter 3W 2 outputs 3000V insulation

Mean Well
Order Code:

05-0252

Brand: Mean Well MPN: DCWN03C-12 EAN-13: 4021087046893
Qty Was Unit Price (Ex VAT)
1+ £7.40 £7.34
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
123 available to back orderBack-order availability date - 09/01/2026

The Mean Well DCWN03C-12 is a DC/DC converter module with a dual-output configuration, delivering up to 125 mA at a total power of 3 W. This converter is typically used in applications requiring efficient power management, particularly in electronic devices where multiple voltage levels are needed. It is suitable for use in various industrial and telecommunications systems, providing reliable direct current conversion solutions.
Input Voltage Range 72V DC
Output Current 125mA
Number of Outputs 2
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 10.2 mm
Efficiency (max.) 87%
Height 10.2mm
Insulation Voltage 3000V DC
Length 31.8mm
Max. output current 125mA
Min. input voltage 36V DC
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Power 3W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 20.3mm
