Mean Well AD-155A SMPSU 13.8V DC 11.5A 151W Enclosed Case Protections

Name: Mean Well AD-155A SMPSU 13.8V DC 11.5A 151W Enclosed Case Protections
Brand: Mean Well
Price: 92.97 GBP
Availability: InStock

Standard range

Order Code:

05-0169

Brand: Mean Well MPN: AD-155A

RoHS Compliant
Country of Origin: China
Free UK shipping available
View Full Product Range (4)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£92.97
5+	£90.66
10+	£88.33
25+	£86.01
50+	£79.04

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

75 in stock, despatched in 4 working days

Product Details
Product Range
Data Sheets
Quick Quote

The Mean Well AD-155A is an enclosed switching power supply with a voltage output of 13.8 V DC and a current rating of 11.5 A, providing a total power output of 151 W. It features a PCB mount and solder lugs, making it suitable for a variety of circuit board powering applications. Typical applications include industrial automation, telecommunications, and security systems where reliable power delivery is essential.

Type	SMPSU
Dim	(L x W x H) 199 x 110 x 50 mm
Height	50mm
Input Voltage	88 - 264 V/AC/124 - 370V DC
Input voltage (max.)	264V AC
Length	199mm
Max. output current	11.5A
Min. input voltage	90V AC
Misc Attribute 1	Synchronised
Misc Attribute 2	AD-155A
Misc Attribute 3	closed
No. of outputs	2
Output current (max.) - rounded	11.5A
Output current 2 (max.)	0.5A
Output voltage (max.)	13.8V DC
Output voltage 2 (max.)	13.3V DC
PFC	Yes
Power	151W
Weight	843.75g
Width	110mm
