IDEC HE5B-M2PN1 HE5B Toggle Switch 125VAC 30VDC 3A IP40 On/Off/On

The Idec HE5B-M2PN1 Toggle switch is a robust component measuring 20 x 20 x 31 mm with a protection rating of IP40 on the front. It supports 125 V AC and 30 V DC with a current rating of 3 A, providing an On/Off/On latch functionality. This switch is ideal for various electrical control applications requiring reliable toggle actions.

Contact Configuration	1 x On/Off/On
Switch Function	latch
Current Rating (Amps)	3A
Actuator Colour	Grey
Casing/button colour	Black
Contact Type	2 change-overs
Dim	(L x W x H) 20 x 20 x 31 mm
Height	31mm
IP Rating	IP40 (Front)
Length	20mm
Lighting Type	None
Max. temperature	+60°C
Min. temperature	-25°C
Recess Diameter	16.2mm
Type	Toggle switch
Width	20mm
