Helukabel 28774-100 Wire H05V-U 1x0.75mm² White 100m

Manufactured by Helukabel, the 28774-100 Wire features a cross-section of 1 x 0.75 mm² and is 100 metres long in a white colour. It is ideal for internal wiring and switchboard applications. The wire is designed for efficient and reliable electrical conductivity.

Colour	White
AWG	Not Specified
Conductor Cross Section	0.75mm²
Number of Cores	1
Conductor Stranding	Not Specified
Insulation Material	Polyvinyl Chloride (PVC)
Length	100m
Type	H05V-U
Cable Diameter	2.50mm
Core layout	Cu-Leiter blank, eindrähtig nach DIN VDE 0295 Kl. 1 / IEC 60228 cl. 1
Max. temperature range (fixed installation)	+80°C
Min. temperature range (fixed installation)	-30°C
Nominal Voltage	300V
Standards	EAC
Test Voltage	2000V
