Helukabel 28773-100 Wire H05V-U 1x0.75 mm² Red 100m

Helukabel's 28773-100 wire is a single-core, 0.75 mm² red wire, extending up to 100 metres in length. It is suitable for internal and switchboard wiring applications. The wire is ideal for use in various electrical appliances due to its durable braid construction.

Colour	Red
AWG	Not Specified
Conductor Cross Section	0.75mm²
Number of Cores	1
Conductor Stranding	Not Specified
Insulation Material	Polyvinyl Chloride (PVC)
Length	100m
Type	H05V-U
Cable Diameter	2.50mm
Core layout	Cu-Leiter blank, eindrähtig nach DIN VDE 0295 Kl. 1 / IEC 60228 cl. 1
Max. temperature range (fixed installation)	+80°C
Min. temperature range (fixed installation)	-30°C
Nominal Voltage	300V
Standards	EAC
Test Voltage	2000V
