Helukabel 28771-100 Wire H05V-U 1x0.75mm² Blue 100m

Helukabel's 28771-100 wire is a blue, 100 m long, single-core wire with a 0.75 mm² cross-section. It is ideal for internal and switchboard wiring applications, providing reliable electrical connections. This high-quality wire is commonly used for wiring braid and braid wire tasks.

Colour	Blue
AWG	Not Specified
Conductor Cross Section	0.75mm²
Number of Cores	1
Conductor Stranding	Not Specified
Insulation Material	Polyvinyl Chloride (PVC)
Length	100m
Type	H05V-U
Cable Diameter	2.50mm
Core layout	Cu-Leiter blank, eindrähtig nach DIN VDE 0295 Kl. 1 / IEC 60228 cl. 1
Max. temperature range (fixed installation)	+80°C
Min. temperature range (fixed installation)	-30°C
Nominal Voltage	300V
Standards	EAC
Test Voltage	2000V
