Helukabel 17000815 HELUPOWER REFLECT Cable 5 G 2.50 mm² Translucent

Manufactured by Helukabel, the HELUPOWER REFLECT Cable 5 G 2.50 mm² is a reflective, fire-defense cable that is transparent-yellow in colour. It highlights enhanced visibility and fire resistance, making it suitable for safety-critical environments. Typical applications include use in emergency lighting systems and fire alarm installations.

Colour	Transparent
Number of Cores	5
Conductor Cross Section	2.50mm²
AWG	Not Specified
Conductor Stranding	Finely stranded
Insulation Material	PP
Length	Sold per metre
Bend radius (no. of ODs for fixed installation)	5
Bend radius (no. of ODs for flexible installation)	10
Cable Diameter	10.70mm
Core layout	Plain copper wire, class 6 according to DIN EN 60228
Halogen-free	No
Material (details)	PUR
Max. temperature range (fixed installation)	+80°C
Max. temperature range (flexible installation)	+80°C
Min. temperature range (fixed installation)	-40°C
Min. temperature range (flexible installation)	-20°C
Number-coded	No
Packaged	Yes
Sold by Metre	Yes
Standards	colored
Suited For Cable Carriers	No
Type	HELUPOWER REFLECT
