The Helukabel MEGAFLEX® 500 Control Lead 13422 is a flame-resistant and oil-resistant cable suitable for industrial environments. This control cable, featuring 12 cores of 1.50 mm² each, is typically used for connecting sensors, actuators, and control panels. Its robust construction makes it ideal for flexible applications requiring reliable signal transmission.
| Type |
Control lead |
| Bend radius (no. of ODs for fixed installation) |
4 |
| Bend radius (no. of ODs for flexible installation) |
10 |
| Cable type |
MEGAFLEX® 500 |
| Core layout |
Cu-blank, according to DIN VDE 0295 Class 5, stranded |
| Cross section |
12 G 1.50 mm² |
| Cross section (each core) |
1.50mm² |
| Factory colour |
Grey |
| Halogen-free |
Yes |
| Insulation |
Halogen-free special polymer |
| Insulation material |
Polymer |
| Manufacturer part # |
13422 |
| Material (details) |
Halogen-free special polymer |
| Max. length sold by the metre |
100m |
| Max. temperature range (fixed installation) |
+80°C |
| Max. temperature range (flexible installation) |
+80°C |
| Min. temperature range (fixed installation) |
-40°C |
| Min. temperature range (flexible installation) |
-30°C |
| Misc Attribute |
MEGAFLEX® 500 |
| No. of leads |
12 G |
| Nominal voltage |
500V |
| Nominal voltage U0 |
300V |
| Number-coded |
Yes |
| Outside Ø |
11.70mm |
| Packaged |
No |
| Sold per metre |
Yes |
| Suited for cable carriers |
No |
| Test voltage |
3000V |
| Wire ID code |
DIN VDE 0293 black wires with consecutive white digit Imprint |
