The Helukabel JZ-500 flexible control cable features 7 cores each with a cross-section of 1 mm², ideal for various control and signal applications. It is especially suitable for use in industrial environments due to its robust design and VDE compliance. The cable is sold per metre, providing flexibility for custom lengths in automation and machinery setups.
| Type |
Control lead |
| Bend radius (no. of ODs for fixed installation) |
4 |
| Bend radius (no. of ODs for flexible installation) |
7.5 |
| Cable type |
JZ-500 |
| Core layout |
Cu-blank, according to DIN VDE 0295, Class 5, fine, BS 6360 Cl.5, IEC 60228 Class 5 |
| Cross section |
7 G 1 mm² |
| Cross section (each core) |
1mm² |
| Factory colour |
Grey |
| Halogen-free |
No |
| Insulation |
Special-PVC |
| Insulation material |
PVC |
| Manufacturer part # |
10068 |
| Max. length sold by the metre |
100m |
| Max. temperature range (fixed installation) |
+80°C |
| Max. temperature range (flexible installation) |
+80°C |
| Min. temperature range (fixed installation) |
-40°C |
| Min. temperature range (flexible installation) |
-15°C |
| Misc Attribute |
JZ-500 |
| No. of leads |
7 G |
| Nominal voltage |
500V |
| Nominal voltage U0 |
300V |
| Number-coded |
Yes |
| Outside Ø |
8.10mm |
| Packaged |
No |
| Sold per metre |
Yes |
| Suited for cable carriers |
No |
| Test voltage |
4000V |
| Wire ID code |
DIN VDE 0293 black wires with consecutive white digit Imprint |
