GW Instek GDS-3504 Digital Oscilloscope 500MHz 4-Channel 4GS/s

The oscilloscopes of the GDS-3000 series of GW Instek offer with a bandwidth of up to 500 MHz and a maximum real-time sampling rate of up to 5 GSa/s efficient measuring instrument for research and laboratory. The Split Screen and zoom function, both the display of the most important waveforms, as well as the simultaneous display matching enlargements.
The oscilloscopes have standard high-speed USB-Host connections at the front and rear side of the device, in order to be able to ensure easy access to stored data.
The integrated SVGA video output makes it possible to the displayed images on a monitor or an external projector.

No. of Channels	4
Bandwidth	500MHz
Type	Digital
Screen Size	800 x 600 p
Calibrated to	Manufacturer's standards (no certificate)
Channel memory depth	25 KP
Channel sample rate	4GS/s
Dim	(L x W x H) 130 x 400 x 200 mm
Height	200mm
Input coupling	AC, DC, GND
Input Impedance	1 MΩ;50 Ω;75O
Input Voltage	300V
Length	130mm
Misc Attribute	GDS-3504
Oscilloscope features	Digital storage (DSO)
Power supply (details)	115 V/AC; 230V AC
Reading Category	CAT I
Resolution	8Bit
Time base	1 ns - 100 s/div
Vertical deflection	2 mV - 5 V/div
Weight	4kg
Width	400mm
