FSP Fortron PPA8504202 VITA 850 GM PC power supply unit 850 W ATX 80 PLUS

FSP Fortron PPA8504202 offers a robust and efficient power solution with the VITA 850 GM PC power supply unit. Designed to deliver a consistent 850 W output, this ATX 80 PLUS Platinum-certified unit ensures optimal energy efficiency, significantly reducing power loss and heat generation within computing environments. Engineered for use within computer systems requiring high power performance and reliability, it suits demanding applications such as gaming rigs, graphic workstations, and servers. With features such as advanced cooling technology and modular cabling, the PSU provides both thermal management and ease of integration into various computer builds. This power supply unit is an excellent choice for engineers and IT professionals seeking to enhance system performance and sustainability.

Power Rating	751 W -
+12 V/DC	70.8A
+5V / DC	3A
-12V / DC	0.3A
20+4 Pin	1
3.3V DC	20A
4+4 pin ATX/EPS 12V	2
4-pin Molex	4
5 V DC	20A
5-pin SATA	8
6-pin PCIe	4
80 PLUS certification	80 PLUS Gold
AC input frequency	50/60 Hz
AC input voltage	100 - 240 V
ATX version	3.1
Bearing technology	HYB
Cables included	CPU, Peripheral (Molex), SATA
Cabling type	Fully-Modular
Combined power (+12V)	850 W
Combined power (+3.3V)	100 W
Combined power (+5V)	100 W
Combined power (+5Vsb)	15 W
Combined power (-12V)	3.6 W
Cooling type	Active
CPU power cable length	70cm
CPU power connector (4+4 pin)	Yes
Depth	140mm
Dimensions	(W x H x D) 150 x 860 x 140 mm
Efficiency	90%
EPS version	2.92
Fan diameter	12 cm
Fan location	Top
Height	860mm
Input Current	11-5.5 A
Max output current (+12V)	70.83 A
Max output current (+3.3V)	20 A
Max output current (+5V)	20 A
Max output current (+5Vsb)	3 A
Max output current (-12V)	0.3 A
Motherboard power cable length	60cm
Motherboard power connector	20+4 pin ATX
Number of fans	1 fan(s)
Number of SATA power connectors	8
Operating Voltage	100 - 240 V
Output rating > 700 W	850W
PCI Express power connectors (6+2 pin)	4
Peripheral (Molex) power connectors (4-pin)	4
Power Factor Correction (PFC) type	Active
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power supply unit (PSU) form factor	ATX
Product colour	Black
Product Type	PC power supply unit
PSU output power	850W
Purpose	PC
SATA power cable length	500mm
Total power	850 W
Type	PC power supply unit
Weight	2.946
Width	150mm
