Finder 78.50.1.230.1202 Series 78 Rail mounted PSU 12-14 V DC 50 W 4.2 A

Finder
Order Code:

03-4427

Brand: Finder MPN: 78.50.1.230.1202 EAN-13: 8012823445014
Qty Was Unit Price (Ex VAT)
1+ £74.09 £73.56
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
4 in stock, despatched in 4 working days

The Finder rail mounted PSU (DIN) with part number 78.50.1.230.1202 delivers a 12 V DC output at 4.6 A, providing 50 W of power. Ideal for industrial applications, this power supply unit offers reliable power distribution and is designed for easy installation on DIN rails. Suitable for use in automation systems.
Type Rail mounted PSU (DIN)
Output Voltage 12V DC
Output Current 4.6A
Power Rating 50W
1st secondary output voltage 12 - 15V
Built-in height N/A
Built-in width N/A
Degree of protection (IP) IP20
Degree of protection (NEMA) N/A
Depth 56.5mm
Direct mounting possible N/A
Efficiency 90%
Height 84mm
Input Voltage 110 - 240V AC
IP Rating IP20
Max. output current 4.6A
Max. output current 1 4.6A
Max. output current 2 N/A
Max. output current 3 N/A
Max. temperature +70°C
Min. input voltage 110V AC
Min. temperature -20°C
Misc Attribute 2 Switched PSU
Nominal Input Voltage 110 - 240 V/AC
Nominal value output current 1 4.2A
Nominal value output current 2 N/A
Nominal value output current 3 N/A
Nominal value output voltage 1 12V
Nominal value output voltage 2 N/A
Nominal value output voltage 3 N/A
Output voltage stabilized true
Performance level according to EN ISO 13849-1 None
Power Consumption 89VA
Power Output 50W
Rated supply voltage AC 50 Hz 110 - 240V
Rated supply voltage AC 60 Hz 110 - 240V
Rated supply voltage DC 220 - 220V
Secondary voltage adjustable false
Short-circuit-proof true
SIL according to IEC 61508 None
Stabilized true
Suitable for distribution board true
Suitable for rail mounting true
Suitable for safety functions false
Type of electric connection Screw connection
Voltage type (supply voltage) AC/DC
Wall mounting possible false
Width 70mm
Width in number of modular spacings 4
