Finder 78.12.1.230.1200 Rail PSU 12V DC 1.25A 12W 110-240V AC input 1pc

Finder
Order Code:

03-4417

Brand: Finder MPN: 78.12.1.230.1200 EAN-13: 8012823375663
Qty Unit Price (Ex VAT)
1+ £34.76
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
4 in stock, despatched in 4 working days

The Finder 78.12.1.230.1200 is a rail-mounted power supply unit delivering 12 V DC at 1.25 A with a power output of 12 W. It is designed for industrial applications requiring compact and reliable DIN rail power solutions. Typical uses include automation systems and panel wiring where stable DC power is essential.
Type Rail mounted PSU (DIN)
Output Voltage 12V DC
Output Current 1.25A
Power Rating 12W
1st secondary output voltage 12 - 12V
Built-in height N/A
Built-in width N/A
Connection Screw terminal
Degree of protection (IP) IP20
Degree of protection (NEMA) N/A
Depth 56.5mm
Dim (L x W x H) 60.8 x 17.5 x 88.8 mm
Direct mounting possible N/A
Height 88.8mm
IP Rating IP20
Length 60.8mm
Max. output current 1.25A
Max. output current 1 1.25A
Max. output current 2 N/A
Max. output current 3 N/A
Max. temperature +60°C
Min. temperature -20°C
Misc Attribute 2 Switched PSU
Nominal Input Voltage 110 - 240 V/AC
Nominal value output current 1 1A
Nominal value output current 2 N/A
Nominal value output current 3 N/A
Nominal value output voltage 1 12V
Nominal value output voltage 2 N/A
Nominal value output voltage 3 N/A
Output type (power supply units) Fixed voltage
Output voltage stabilized true
Performance level according to EN ISO 13849-1 None
Power Consumption 32VA
Power Output 12W
Rated supply voltage AC 50 Hz 110 - 240V
Rated supply voltage AC 60 Hz 110 - 240V
Rated supply voltage DC 220 - 220V
Secondary voltage adjustable false
Short-circuit-proof true
SIL according to IEC 61508 None
Stabilized true
Suitable for distribution board true
Suitable for rail mounting true
Suitable for safety functions false
Type of electric connection Screw connection
Voltage type (supply voltage) AC/DC
Wall mounting possible false
Width 17.5mm
Width in number of modular spacings 1
