Finder 77D182308650 SSR 60A 660V AC zero crossing Switching

The Finder SSR 77D182308650 is a solid state relay designed with a maximum switching voltage of 660 V AC and supports zero crossing functionality. This electronic relay, rated for 60 A, is ideal for safe and reliable industrial automation applications. Typical uses include controlling high-power loads and managing circuits in manufacturing equipment and HVAC systems.

Type	SSR
Input Voltage	660VAC
Contact Configuration	SPST-NO
Switching Current	60A
Switching Voltage	660VAC
Length	59mm
Width	45mm
Height	29.40mm
IP Rating	IP20
Maximum Temperature	+80°C
Min. temperature	-30°C
Misc Attribute	77.D1.8.230.8650
Number of Phases	1
Operating Voltage	24 - 660
Permanent current (max.)	60A
Rated control supply voltage AC 50 Hz	230 - 230V
Rated control supply voltage AC 60 Hz	230 - 230V
Rated operation current Ie at AC-1	60A
Rated operation current Ie at AC-3	N/A
Rated operation current Ie at AC-51	N/A
Rated operation current Ie at AC-53a	N/A
Rated operation current Ie at AC-53b	N/A
Suitable for distribution board	true
Switching at zero-crossing	true
Switching type	Zero crossing
Switching voltage (min.)	24V AC
Voltage type for actuating	AC
