Finder 77B182308650 SSR 40A 660V AC Zero crossing 1pc

Finder's solid state relay, model 77B182308650, is designed for semiconductor switching with a maximum voltage of 660 V AC and a current rating of 40 A. Featuring zero crossing technology, this SSR is ideal for applications requiring smooth operation and reduced electrical noise. It is commonly used in industrial automation and control systems.

Type	SSR
Contact Configuration	SPST-NO
Switching Current	40A
Length	59mm
Width	45mm
Height	29.40mm
IP Rating	IP20
Max. temperature	+80°C
Min. temperature	-30°C
Misc Attribute	77.B1.8.230.8650
Number of Phases	1
Operating Voltage	24 - 660
Permanent current (max.)	40A
Rated control supply voltage AC 50 Hz	230 - 230V
Rated control supply voltage AC 60 Hz	230 - 230V
Rated operation current Ie at AC-1	40A
Rated operation current Ie at AC-3	N/A
Rated operation current Ie at AC-51	N/A
Rated operation current Ie at AC-53a	N/A
Rated operation current Ie at AC-53b	N/A
Suitable for distribution board	true
Switching at zero-crossing	true
Switching type	Zero crossing
Switching voltage (min.)	24V AC
Voltage type for actuating	AC
