The Finder plug-in relay 56.34.8.230.4040 is designed for PCB mounting and operates at 230 V AC with a current rating of 12 A. It features four change-over contacts, making it suitable for versatile switching applications. This relay is typically used in automation systems and industrial control panels.
| Coil Voltage |
230V AC |
| Contact Configuration |
4CO (4PDT) |
| Switching Current |
12A |
| Coil Resistance |
7700Ω |
| Complete with socket |
false |
| Connection |
Type C CEE 7/16 plug 4.8mm |
| Contact Material |
AgSnO2 |
| Control Mode |
monostable, 1 coil |
| Degree of protection (IP) |
N/A |
| Depth |
27.7mm |
| Dimensions |
(L x W x H) 40.8 x 27.7 x 37.1 mm |
| Drive, polarization |
Polarity free |
| Drive, switching attitude |
Mono stable |
| Height |
37.1mm |
| IP Rating |
Relay protection type RT I |
| Length |
40.8mm |
| Material contact |
Other copper alloys |
| Material of contact insert |
Duroplast |
| Material of contact surface |
Untreated |
| Max. pick-up Voltage |
253V AC |
| Max. switching capacity |
3000VA |
| Maximum Temperature |
+70°C |
| Min. pick-up Voltage |
184V AC |
| Min. temperature |
-40°C |
| Minimum Operating Temperature |
-40°C |
| Mounting Type |
PCB |
| Nominal Current |
12A |
| Number of contacts as change-over contact |
4 |
| Number of contacts as normally closed contact |
0 |
| Number of contacts as normally open contact |
0 |
| Rated control supply voltage AC 50 Hz |
230 - 230V |
| Rated control supply voltage AC 60 Hz |
230 - 230V |
| Switching Voltage Max |
400V AC |
| Type |
Plug-in relay |
| Type of electric connection |
Plug-in connection |
| Type of switch contact |
Single contact |
| Voltage type for actuating |
AC |
| Width |
27.7mm |
| With detachable clamps |
N/A |
| With forced-guided contacts |
false |
| With LED indication |
true |
