Finder 50.12.9.125.1000 PCB Relay 125V DC 8A 2 change-overs AgNi contacts

Finder's PCB relay, model 50.12.9.125.1000, supports 125 V DC and a current of 8 A with 2 change-over contacts. This compact component is ideal for printed circuit boards, offering reliable switching capabilities. It's typically used in industrial and automation applications requiring precise control.

Coil Voltage	125V DC
Contact Configuration	2CO (DPDT)
Switching Current	8A
Connection	Print
Depth	29mm
Dimensions	(W x H x D) 12.4 x 25 x 29 mm
Evaluation inputs	2-channel
Height	25mm
IP Rating	IP40
Length	29.0mm
Model	Other
Mounting Type	PCB
Number of outputs, safety related, delayed, semiconductors	N/A
Number of outputs, safety related, delayed, with contact	N/A
Number of outputs, safety related, undelayed, semiconductors	N/A
Number of outputs, safety related, undelayed, with contact	2
Number of outputs, signalling function, delayed, semiconductors	N/A
Number of outputs, signalling function, delayed, with contact	N/A
Number of outputs, signalling function, undelayed, semiconductors	N/A
Number of outputs, signalling function, undelayed, with contact	N/A
Performance level according to EN ISO 13849-1	N/A
Rated control supply voltage DC	125 - 125
SIL according to IEC 61508	N/A
Stop category according to IEC 60204	N/A
Suitable for monitoring of emergency-stop circuits	true
Suitable for monitoring of magnetic switches	N/A
Suitable for monitoring of optoelectronic protection equipment	N/A
Suitable for monitoring of position switches	N/A
Suitable for monitoring of proximity switches	N/A
Suitable for monitoring of tactile sensors	N/A
Suitable for monitoring of valves	N/A
Suitable for rail mounting	false
Type	PCB relay
Type of electric connection	PCB connection
Type of safety according to IEC 61496-1	N/A
Voltage type for actuating	DC
Width	12.4mm
With approval according to UL	true
With approval for BG BIA	N/A
With approval for TÜV	true
With detachable clamps	false
With feedback circuit	N/A
With muting function	N/A
With start input	N/A
