Finder 46.61.8.110.0040 Relay 110V AC 16A Faston 187 mechanical display

The Finder 46.61.8.110.0040 is a plug-in relay designed for 110 V AC, supporting 16 A with a single change-over contact. It is commonly used in printed circuit board applications and suitable for various switching tasks. This mini relay is ideal for automation systems and control panels.

Coil Voltage	110V AC
Contact Configuration	1CO (SPDT)
Switching Current	16A
Complete with socket	false
Connection	Connector
Degree of protection (IP)	N/A
Depth	29mm
Dimensions	(W x H x D) 12.4 x 32.8 x 29 mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Height	32.8mm
IP Rating	IP40
Length	29.0mm
Material contact	Other copper alloys
Material of contact insert	Thermoplastic
Material of contact surface	Untreated
Mounting Type	Faston
Nominal Current	16A
Number of contacts as change-over contact	1
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Rated control supply voltage AC 50 Hz	110 - 110V
Rated control supply voltage AC 60 Hz	110 - 110V
Type	Plug-in relay
Type of electric connection	Plug-in connection
Type of switch contact	Single contact
Voltage type for actuating	AC
Width	12.4mm
With detachable clamps	N/A
With forced-guided contacts	false
With LED indication	true
