Finder 34.51.7.024.4010 PCB Relay 24V DC 6A 5mm slim safe isolation

Finder's PCB relay 34.51.7.024.4010 features a 24 V DC coil, handling currents up to 6 A with a single change-over contact. This compact relay is designed for printed circuit boards, making it ideal for use in electronic devices and industrial control systems. Typical applications include automation equipment and home appliances.

Coil Voltage	24V DC
Contact Configuration	1CO (SPDT)
Switching Current	6A
Complete with socket	false
Connection	Solder pins
Contact Material	AgSnO2
Control Mode	monostable, 1 coil
Degree of protection (IP)	N/A
Depth	28mm
Dimensions	(L x W x H) 28 x 5 x 15 mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Height	15mm
Length	28.0mm
Material contact	Other copper alloys
Material of contact insert	Thermoplastic
Material of contact surface	Untreated
Maximum Temperature	+85°C
Min. temperature	-40°C
Minimum Operating Temperature	-40°C
Mounting Type	PCB
Nominal Current	6A
Number of contacts as change-over contact	1
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Rated control supply voltage DC	24 - 24V
Switching Voltage	24 V/DC/250V AC
Switching Voltage Max	250V AC
Type	PCB relay
Type of electric connection	PCB connection
Type of switch contact	Single contact
Voltage type for actuating	DC
Width	5.0mm
With detachable clamps	N/A
With forced-guided contacts	false
With LED indication	false
