Eaton 278555 FAZ-C6/1 circuit breaker 6A 230V AC 1pc

Eaton manufactures the 278555 FAZ-C6/1 circuit breaker, which is rated at 6 A and 230 V AC. This circuit breaker protects electrical circuits from overloads and short circuits. It is typically used in residential and commercial electrical installations.

Type	Circuit breaker
Additional equipment possible	TRUE
Ambient temperature during operating	-25-75°C
Built-in depth	70.5mm
Concurrently switching neutral conductor	FALSE
Connectable conductor cross section multi-wired	1-25mm²
Connectable conductor cross section solid-core	1-25mm²
Current limiting class	3
Degree of protection (IP)	IP20
Explosion-proof	FALSE
Flush-mounted installation	FALSE
Frequency	50-60Hz
Nominal current	6A
Nominal current - rounded value	6A
Nominal voltage	230V AC
Number of pins	1
Number of poles (total)	1
Number of protected poles	1
Overvoltage category	3
Pollution degree	2
Power loss	1.2W
Rated Current	6A
Rated impulse withstand voltage Uimp	4kV
Rated insulation voltage Ui	440V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	10kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	15kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	15kA
Rated voltage	230V
Release characteristic	C
Release characteristics	C
RoHS-compliant	Yes
Switch-off capacity	15kA
Voltage type	AC
Weight	0
Width in number of modular spacings	1
