The Eaton impulse changeover switch Z-S109/W is a versatile device rated at 16 A for effective surge protection. It is designed for installation on DIN rails, ensuring easy integration into electrical systems. This switch is typically used in applications requiring reliable changeover functions and surge protection.
| Type |
Impulse changeover switch |
| Built-in depth |
60mm |
| Contact type |
1 change-over |
| Control voltage 1 |
110-110V |
| Control voltage 2 |
0-0V |
| Depth |
60mm |
| Frequency control voltage 1 |
0-0Hz |
| Frequency control voltage 2 |
0-0Hz |
| Function |
Mechanical switch |
| Max. incandescent lamp load |
2024W |
| Max. load fluorescent lamp |
2500VA |
| Max. load fluorescent lamp (Duo circuit) |
2500VA |
| Max. load fluorescent lamp (parallel compensated) |
2500VA |
| Max. operating voltage |
230V DC |
| Max. switching current (cos phi = 0.6) |
24A |
| Max. temperature |
+45°C |
| Min. operating voltage |
24V DC |
| Min. temperature |
-20°C |
| Misc Attribute |
Z-S109/W |
| Mounting method |
DIN rail |
| Mounting Type |
DIN rail |
| Number of contacts as change-over contact |
1 |
| Number of contacts as normally closed contact |
0 |
| Number of contacts as normally open contact |
0 |
| Operating voltage |
24 - 230 V DC |
| Permanent current (max.) |
24A |
| Rated switch current |
16A |
| Suitable for manual operation |
TRUE |
| Supply Voltage |
24-230V |
| Switching current (max.) |
16A |
| Type of control voltage 1 |
DC |
| Type of control voltage 2 |
DC |
| Voltage type (supply voltage) |
DC |
| Width in number of modular spacings |
1 |
