Eaton 187237 afdd fire protection switch 40 A 230 V AC 30 mA

The Eaton AFDD 187237 is a 2-pin arc fault detection device with a 40 A current rating, 0.03 A leakage current, and operates at 230 V AC. It enhances electrical safety by detecting arc faults and is widely used in residential and commercial electrical systems. Ideal for protecting against electrical fires, it ensures compliance with modern safety standards.

Type	AFDD
Additional equipment attached at delivery	Fire protection switch
Built-in depth	67mm
Compatible with (details)	Circuit breaker switch
Concurrently switching neutral conductor	FALSE
Control voltage type auxiliary equipment	AC
Current limiting class	3
Degree of protection (IP)	IP20
Differential current rating	0.03A
Frequency	50Hz
Leakage current type	A
Nominal current	40A
Nominal current - rounded value	40A
Nominal voltage	230V AC
Number of pins	2
Number of Poles	2
Overvoltage category	3
Pollution degree	2
Rated Current	40A
Rated fault current	0.03A
Rated short-circuit breaking capacity according to EN 61009	6kA
Rated short-circuit breaking capacity according to IEC 60947-2	0kA
Rated switch current auxiliary device	0A
Rated voltage	230V
Rated voltage auxiliary device	230V
Release characteristic	B
Release characteristics	B
Width in number of modular spacings	3
