Eaton 185586 C22-DL-G-K10-24-P62 Pushbutton green planar 1pc

Image Representative of Range

Eaton 185586 C22-DL-G-K10-24-P62 Pushbutton green planar 1pc

Eaton
Order Code:

02-5843

Brand: Eaton MPN: 185586 EAN-13: 4015081810802
Qty Unit Price (Ex VAT)
1+ £37.71
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack order, lead time 4 weeks

The Eaton 185586 C22-DL-G-K10-24-P62 is a green pushbutton switch designed for planar mounting. It features a robust design for reliable operation, making it suitable for industrial and control applications. Typical uses include machinery control panels and various automation systems.
Type Pushbutton
Switch Function 1 maker
Current Rating 4A
Bulb Type LED (monochrome)
Colour Green
Colour button Green
Colour front ring Titanium
Connection Open end cable
Construction type lens Round
Degree of protection (IP) IP67/IP69K
Degree of protection (NEMA) 12
Factory colour Green
Height opening 0mm
Hole Diameter 22.5mm
IP Rating IP69K
Lighting type Area illumination
Material front ring Plastic
Max. temperature +70°C
Min. temperature -25°C
Misc Attribute C22-DL-G-K10-24-P62
Number of command positions 1
Number of contacts as change-over contact 0
Number of contacts as normally closed contact 0
Number of contacts as normally open contact 1
Print motif None
Recess diameter 22mm
Shape Round
Spring-return TRUE
Suitable for lighting TRUE
Supply voltage lamp 24V
Switch/button features planar
Switching function latching FALSE
Switching Voltage 24V DC/AC
Transparent FALSE
Type of button Flat
Type of electric connection Cable
Width opening 0mm
With front ring TRUE
