EAO 51-131.0252 Illuminated pushbutton mom SA 1NC+1NO ST D18 gold/silver

EAO 51-131.0252 is an illuminated pushbutton featuring momentary action with contact configurations of 1 normally closed (NC) and 1 normally open (NO) contact set. This device is designed with a standard size of 18 mm in diameter, and it is built with gold and silver materials to ensure durability and reliable conductivity. The pushbutton provides a robust solution for control panels and operator interfaces where an immediate and clear visual indication is required.

Type	Pushbutton
Approbations	Cb (iec 61058-1), Cqc, Csa, Dnv, Eac, Enec (en 61058-1), Ul, Vde
Climate Resistance	Standard Condition, As Per Din En 60068-2-30 | Changing Condition, As Per Din En 60068-2-14
Conformities	Ce, Ukca, 2011 / 65 / Ec (rohs), 2014 / 30 / Eu (emc), 2014 / 35 / Eu (lvd)
Contacts Concat	1 Nc / 1 No
Contacts Material	Gold
Design	Raised
Electrical Lifetime	50 000 Cycles Of Operation
Erp Ehq Custom Number	8536.5000
Erp Ehq Source Country	Ch
Front Bezel Colour	Black
Front Bezel Material	Plastic
Front Dimension Concat	Ø 18mm
Front Form	Round
Ip Front Protection	Ip65, According To Din En 60529
Lens Illumination	Illuminated
Mechanical Lifetime	2 Mil. Cycles Of Operation
Operating Temperature	– 25 °c … + 55 °c, Mounted As A Block, Make Sure The Heat Can Escape Freely
Output Hsd	Yes
Protection Class	Ll
Shock Resistance	15 G For 11 Ms, As Per Din / En 60512-4-3, Din / En 60068-2-27 (single Impacts, Semi-sinusoidal)
Switching Action Concat	Momentary
Switching System	Snap-action Switching Element
Terminal Concat	Soldering terminal
Thermal Current Ith	The Maximum Current In Continuous Operation And At Ambient Temperature Not Exceeding The Quoted Maximum Values. | 3 A
Vibration Resistance	10 G At 10 Hz…1500 Hz, Amplitude 0.75 Mm (sinusoidal), According To Din En 60512-4-4, Din En 60068-2-6
Weight	0.00585
