EAO 46-2Y50.101C.000 USB socket 3.0 type C-A (female-female)

EAO 46-2Y50.101C.000 is a USB socket 3.0 type C-A designed for female-to-female connections, exhibiting high-speed data transfer capabilities typical of USB 3.0 technology. This component is engineered to provide reliable connectivity and durability, ensuring consistent performance even in demanding environments. Its robust construction and precise design make it ideal for integration into industrial equipment, computer peripherals, and telecommunications devices, where efficient and stable data connections are crucial.

Type	USB socket
Gender	Socket
No. of Contacts	9
Mounting Direction	Panel
Climate Resistance	+40°c-92%rh
Conformities	Ce
Design	Raised
Electrical Lifetime	>50 000 H
Erp Ehq Custom Number	8538.9000
Erp Ehq Source Country	It
Front Bezel Colour	Black
Front Bezel Material	Plastic
Front Dimension Concat	Ø 29mm
Front Form	Round
Ip Front Protection	Ip20 / Ip66 With Cap Closed (iec-en60529)
Mechanical Lifetime	>15 000 Insertion Cycles
Mounting Cut Out Dps Concat	Ø 22mm
Operating Temperature	– 25 °c … + 55°C
Output Hsd	Yes
Shock Resistance	30g, 18ms (en-iec 60068-2-27)
Standards Norms	Csa C22-2, Iec En 60947-1, Iec En 60947-5-1, Ul508
Terminal Concat	Usb 3.0 Socket Type C-a
Vibration Resistance	5g F= 2...500hz (en-iec 60068-2-6)
Weight	0.022
