EAOs 46-2131.3150.000 is a guarded push-button featuring a green actuator in a robust metal construction, designed to provide reliable operation in demanding environments. This component incorporates a protective guard to prevent accidental activation, ensuring only deliberate engagement by the user. The durable metal housing enhances its resistance to mechanical wear and environmental factors, making it suitable for both indoor and outdoor applications. Typical engineering applications include heavy machinery control panels, industrial equipment interfaces, and other environments where safety and reliability are paramount.
| Type |
Pushbutton |
| IP Rating |
Ip65 |
| Climate Resistance |
+25°c-97%rh / +45°c-93%rh (iec-en60068-2-30) |
| Conformities |
Ce |
| Design |
Raised |
| Erp Ehq Custom Number |
8538.9000 |
| Erp Ehq Source Country |
It |
| Front Bezel Colour |
Silver |
| Front Bezel Material |
Metal |
| Front Dimension Concat |
Ø 29,5mm |
| Front Form |
Round |
| Ik Front Protection |
Ik03 |
| Lens Colour |
Green |
| Lens Illumination |
Non Illuminated |
| Lens Material |
Plastic |
| Lens Shape |
Flush |
| Max No Modules |
6 |
| Mechanical Lifetime |
1 Mil. Cycles Of Operation (rcc/rpb) |
| Mounting Cut Out Dps Concat |
Ø 22mm |
| Operating Temperature |
– 25 °c … + 55°C |
| Output Hsd |
Yes |
| Protection Class |
Ll |
| Shock Resistance |
30g, 18ms (en-iec 60068-2-27) | 50g, 11ms (en-iec 60068-2-27) |
| Standards Norms |
Csa C22-2, Iec En 60947-1, Iec En 60947-5-1, Ul508 |
| Switching Action Concat |
Momentary |
| Vibration Resistance |
5g F= 2...500hz (en-iec 60068-2-6) |
| Weight |
0.033 |
