The Doepke RCCB is designed for protecting electrical circuits with a 40 A rating and a leakage current sensitivity of 0.03 A. It is suitable for use in both residential and commercial settings to prevent electrical faults. The device operates on a voltage range of 230 V to 400 V, with the neutral conductor positioned on the right.
| Type |
RCCB |
| Current Rating |
40A |
| Voltage Rating - AC |
230V AC |
| No. of Poles |
4 |
| Tripping Characteristics |
A Curve |
| Additional equipment possible |
true |
| Ambient temperature during operating |
-25 - 40°C |
| Built-in depth |
69mm |
| Colour |
Grey |
| Connectable conductor cross section multi-wired |
1.5 - 50mm² |
| Connectable conductor cross section solid-core |
1.5 - 50mm² |
| Current Ratng |
40A |
| Degree of protection (IP) |
IP20 |
| Depth |
75mm |
| Device depth |
75mm |
| Device height |
85mm |
| Device width |
72mm |
| Differential current rating |
0.03A |
| Dim |
(W x H x D) 72 x 85 x 75 mm |
| Duty class |
gG |
| Explosion-proof |
false |
| Frequency |
50 Hz |
| Height |
85mm |
| Leakage current type |
A |
| Mounting method |
DIN rail |
| Number of pins |
4 |
| Number of Poles |
4 |
| Pollution degree |
2 |
| Power loss |
3.6W |
| RAL-number (similar) |
7035 |
| Rated current |
40A |
| Rated fault current |
0.03A |
| Rated impulse withstand voltage Uimp |
4kV |
| Rated insulation voltage Ui |
400V |
| Rated voltage |
400V |
| Selective protection |
false |
| Short-circuit breaking capacity (Icw) |
10kA |
| Short-time delayed tripping |
false |
| Surge current capacity |
0.25kA |
| Type of personal protection PRCD |
N/A |
| Voltage type |
AC |
| Width |
72mm |
| Width in number of modular spacings |
4 |
| With interlocking device |
true |
