Dehner Elektronik SPE 500-24 SMPSU 24V 21A 500W For AV & IT Applications

The Dehner Elektronik SPE 500-24 (24V 21A) is a 500 W switched-mode power supply unit delivering 24 V DC at 21 A. This PCB-mount power supply, equipped with solder lugs, is ideal for integration in sophisticated electronic equipment. It is commonly used in industrial and commercial applications requiring reliable and efficient power management.

Output Voltage	24V DC
Output Current	21A
Power Rating	500W
Number of Outputs	1
Input Voltage	264V AC
Connection	Screw terminal
Dimensions	(L x W x H) 235 x 127 x 41 mm
Height	41mm
Length	235mm
Maximum Operating Temperature	70°C
Maximum Temperature	85°C
Min. temperature	-40°C
Minimum Input Volage	85V AC
Misc Attribute 2	closed
MTBF	179000h
PFC	Yes
Type	SMPSU
Weight	1223g
Width	127mm
