Dehner Elektronik SPE 200-48 SMPSU 48V DC 4.2A 200W High Efficiency

The Dehner Elektronik SPE 200-48 SMPSU is a versatile printed circuit board power supply unit providing 48 V DC at 4.2 A, with a total power output of 200 W. It features AC/DC conversion with solder lugs for easy mounting and connection. This power supply unit is ideal for various industrial and electronic applications requiring reliable DC power.

Output Voltage [DC]	48V
Output Current	4.2A
Power Rating	200W
Number of Outputs	1
Input Voltage	85-264VAC: 120V-375VDC
Connection	Screw terminal
Dimensions	(L x W x H) 212 x 115 x 30 mm
Height	30mm
Length	212mm
Max. operating temperature (derating)	70°C
Maximum Operating Temperature	50°C
Maximum Temperature	85°C
Min. temperature	-40°C
Misc Attribute 1	Switched PSU
Misc Attribute 3	closed
MTBF	177300h
Operating temperature (min.)	-30°C
Output Voltage	48V DC
PFC	Yes
PSU features	Regulated
Type	SMPSU
Weight	670g
Width	115mm
